3PH-400V-50HZ 50HP Air-cooled Box Chiller

China Easy-maintainable 3PH-400V-50HZ 50hp Air-cooled Box Chiller with 12 months Warranty Suppliers.This is a CE-certified chiller. It can be installed without a cooling tower, easy to install, easy to move, and fast cooling 50HP horsepower chiller.

Model:JSFL-50-C

Send Inquiry

Product Description


3PH-400V-50HZ 50hp Air-cooled Box Chiller


Introduction

This is a tailor-made 3PH-400V-50HZ 50HP air-cooled water chiller. Large box-type chiller with a cooling capacity of 158KW (135880Kcal/hr) and maximum flow rate of 700L/Min, customized for a Japan electronics facility.



Model: JSFL-50-C

Power specification: 3PH-400V-50HZ

Brand: Jiusheng

Compressor power: 50HP/37.5KW
Temperature control range: 5-35℃
Pump power: 3.75W
Pump flow: 700L/MIN
Pump head: 16M
Cooling capacity: 158KW/hr (135880Kcal/hr)
Refrigerant: R404A


Minimum order quantity: 1 set

Payment method: wire transfer, EXW, FOB/negotiation

Price: Negotiable

Place of Origin: Dongguan City, Guangdong Province, China

Certificate: CE

Delivery time: 10-20 days/negotiation

Service: OEM / ODM

Supply Ability: 1000PCS/month

Packing: plywood packing


3PH-400V-50HZ 50hp Air-cooled Box Chiller display and advantages

1.50hp Air-cooled Box Chiller,High-precision temperature control and high-speed cooling efficiency, and energy-saving and environmentally friendly operation.

2. 50hp Air-cooled Box Chiller,Famous brand accessories in our industrial chillers

We use world-renowned accessories in our air-cooled industrial chillers. under normal operation, can be used for more than 10 years.

Panasonic/Daikin/Copeland compressors, Schneider Electric, Multi-stage centrifugal pump, Talos copper pipes, etc.


3PH-400V-50HZ 50hp Air-cooled Box Chiller parameters

Air-cooled Chiller Model # JSFL-50-C
Cooling Capacity Kw 158
Kcal/h 135880
Power Supply Voltage 3PH-400V-50HZ
Overall Power Input Kw 45.25
Operation Current A 70
Compressor Brand Copeland
Type Scroll, Full-hermetic
Power input(Kw) 9.4*4PCS
Cooling Fan Brand Maer (Zhejiang)
Type External rotor axial fan
Power (Kw) 1*4PCS
Pump
Brand Yangtzy River
Type Horizontal multi-stage centrifugal
Power(Kw) 11
Flow rate (m³/H) 42
Pump Head (M) 79
Condenser Type Aluminum fin & Copper tube
Evaporator Type Coil
Material 100% copper
Water Tank Material SUS Stainless steel
Volume 400L
Pipe fitting øMedium Outlet DN80
øMedium Inlet DN80
Temperature
Digital Display
Panel brand BANGPU
Display Push-button digital display
Electrical AC Contactor Schneider, France
Temp Range +5℃ - +35℃
Temp Accuracy ±1℃
Water Pressure Pressure Guage
Water Flowrate Flowrate Meter
Alarming System Abnormal Temp.
Phase reverse
High/Low Pressure Fault Pressure Switch
Compressor overload Thermo-relay
Compressor overheat
Pump overload Thermo-relay
Lower water level Level switch
Short-circuit Air switch
Cooling medium TAP-water
Refrigerant R404A
Measurement L*W*H (mm) 2010*1670*1750
Net Weight Kgs 1800


Why buy a chiller from us?

A. Leading manufacturer of industrial chillers for 20 years.

B. Expert in industrial cooling solutions.

C. Many customized services can be provided for industrial chillers.

D. Stable quality + fast delivery time + reasonable price + strong technical support + intimate after-sales service.

E. Our industrial chillers have passed CE certification.


Applications onsite
