Product Description

20hp Stainless Steel Air-cooled Shell And Tube Chiller

Introduction

20hp Stainless Steel Air-cooled Shell And Tube Chiller is a CE-certified chiller. It can be installed without a cooling tower, easy to install, easy to move, and fast cooling, suitable for application with rust-proof reqruirement.

The unit adopts full hermetic scroll compressor from international brands such as Panasonic, Copeland, and Daikin. stable operation, low noise, fast cooling. Simple to use and easy to operate.

The standard temperature can be controlled from 5-35℃, and the non-standard type can be customized for ultra-low temperature -50℃.

Model: JSKG-20-SS

Brand: Jiusheng

Minimum order quantity: 1 set

Payment method: T/T, or by negotiation

Price: Negotiable

Place of Origin: Dongguan, Guangdong, China

Certificate: CE

Delivery time: 10-20 days/negotiation

Service: OEM / ODM

Supply Ability: 500PCS/month

Packing: plywood packing

Features

1. Whole-body stainless steel 304

2. Stainless steel box with water proof cover for control panel;

3. Stainless steel V-type finned condenser;

4. Stainless steel shell and tube evaporator;

5. Human-friendly remote controll device for easy access

Parameters

Model #		JSKG-20-SS
Nominal Cooling Capacity	kW	60
Nominal Cooling Capacity	Kcal/h	51600
Power Supply	3PH-380V-60HZ
Total Power Input	kW	17.76
Operation Current	A	28
Compressor	Brand	Panasonic/Daikin
	Type	Full-hermetic scroll
	Power input（kW）	7.35 * 2PC
Cooling Fan	Type	External rotor axial fan
Cooling Fan	Power (kW)	0.78 * 2PC
Pump	Power(kW)	1.5
	Flow rate (m³/h)	21.6
	Pump head (m)	15
Condenser	Type	Aluminum finned Copper tube
Evaporator	Type	Shell and Tube
Pipe fitting	ø Medium Outlet	DN50
Pipe fitting	ø Medium Inlet	DN50
Electrical	AC Contactor	Schneider
Cooling Condition	Ambient Temp.	35℃
	Chilled Water Temp Range	5℃ - 30℃
	Temp Accuracy	±1℃
Alarming System	Abnormal Temperature, Phase reverse, High/Low Pressure Fault, Compressor overload, Compressor overheat, Pump overload, Medium low level, Short-circuit


Temperature Display	Push-button digital display
Cooling medium	Tap-water
Refrigerant	R22 / R404A / R47C / R410A / R134A
Measurement	LWH(mm)	19608301760
Net Weight	Kgs	840

Why choose Jiusheng?

Jiusheng has focused on the refrigeration industry for 20 years. We are committed to manufacturing various industrial chillers. After 20 years of development, Jiusheng can provide many different types of industrial chillers, such as air-cooled chillers, water-cooled chillers, high and low temperature Controlled chillers, screw chillers, open chillers, all customized chillers, and oil coolers are widely used in many industries all over the world.

According to regular customer feedback, the quality of Jiusheng chillers is very good. Under normal operation, the lifecycle can be extended to more than 10 years.

Why buy a chiller from us?

A. Leading manufacturer of industrial chillers for 20 years.

B. Expert in industrial cooling solutions.

C. Many customized services can be provided for industrial chillers.

D. Stable quality + fast delivery time + reasonable price + strong technical support + intimate after-sales service.

E. Our industrial chillers have passed CE certification.

Applications
